0603 SMD LED Yellow 585-595nm Amber light 1608 chip LED for led display indicator
Product Details:
| Place of Origin: | China |
| Brand Name: | BOSMFC |
| Certification: | Rohs, Reach |
| Model Number: | 0603 SMD LED |
Payment & Shipping Terms:
| Minimum Order Quantity: | 4000pcs |
|---|---|
| Packaging Details: | 4000pcs/reel, Reel+Anti-static bag+carton |
| Delivery Time: | 5-15 days |
| Payment Terms: | T/T, Western Union, paypal |
| Supply Ability: | 500KK/month |
|
Detail Information |
|||
| Application: | Indoor & Outdoor Lighting | Power: | 0.06 W |
|---|---|---|---|
| Emitting Color: | Yellow | Wavelength: | 584-596nm |
| Forward Current: | 20mA | Forward Voltage: | 1.8-2.4v |
| Luminous Flux: | 100-300mcd | Viewing Angle: | 120° |
| Size: | 1.6*0.8*0.6mm | Color Rendering Index (Ra): | 85 |
| Operating Temperature(℃): | -40 - +85 | Storage Temperature(℃): | -40 - +100 |
| Lifespan: | 50,000 Hours | Warranty: | 3 Years |
| Chip Brand: | San'an Chip / Epistar Chip | Package: | 4000pcs/reel |
| Highlight: | 0603 yellow led light,0603 smd led light,0603 smd size |
||
Product Description
0603 SMD LED Yellow 585-595nm Amber light 1608 chip LED for led display indicator
0603 SMD LED---Lanjin catalog.pdf
Features:
- Energy saving and environmental protection
- Long life span
- Good heat dissipation
- Low light attenuation
- Easy installation
- Strong anti-static ability
- RoHS certification
Technical Parameters:
Electrical optical characteristics of 0603 Top smd led:(Ta=25°C)
| Parameter | Symbol | Color | Min | Typ | Max | Unit | Test Condition |
| Wavelength | λd | Yellow | 584 | --- | 596 | nm | IF=20mA |
| Luminous intensity | Iv | Yellow | 150 | --- | 300 | mcd | IF=20mA |
| Forward voltage | VF | Yellow | 1.8 | --- | 2.4 | V | IF=20mA |
| Viewing angle | --- | 120 | --- | deg | IF=20mA | ||
| Reverse current | IR | Yellow | --- | ---- | 5 | uA | IF=20mA |
| Operation Temperature | －40~+85℃ | Size | 1.6*0.8*0.6mm |
| Storage Temperature | －40~+100℃ | Packing | 4000pcs/reel |
Applications:
- Indoor and outdoor commercial light
- LED backlight and SMD type indicator
- LED module and LED strip light
- Decoration light, backlight in dashboards and switches
- Auto lamp, automotive electronics, traffic lights
- Mobile phone, digital camera, flash photoelectric display, backlight display
- LED Taillight, LED Brake Light , Turn light , Daytime Running Light ,License plate lamp ,In-vehicle lighting
Materials:
Company information:
|
Dongguan Lanjin Optoelectronics Co., Ltd., established in 2005, is a professional manufacturer specializing in the production of light-emitting diodes (LEDs), LED digital displays, SMD LEDs, through-hole LEDs, and LED PCB assembly services. Our factory covers an area of 2,500 square meters and features modern purification facilities, constant temperature and humidity control, and anti-static production workshops. We are proud to have obtained ISO9001:2015 international Quality Management System certification, and we are currently in the process of applying for ISO14001 Environmental Management System certification. With 18 years of development, we have achieved two national invention patents, twelve practical new-type patents, and two software invention patents. All our products are in compliance with the EU RoHS standard, demonstrating our commitment to environmental sustainability. Lanjin Optoelectronics has incorporated advanced manufacturing technologies from Japan, Korea, and Western Europe. With a focus on high-quality market positioning, we have developed high-temperature resistant and long-life LED products. Our LEDs find wide applications in communication equipment, switching power supplies, decorative lighting, multi-speakers, DVDs, and other electronic devices. At Lanjin, we adhere to the principle of "Quality and Customer First" and are dedicated to providing customized services to meet our customers' specific demands. We welcome your inquiries and strive to solve your questions and challenges. Our mission is to light up the world with LED technology while brightening your life. |
Packing and Shipping:
Inner packaging: Anti-static Bag Vacuo Packaging
Outer packaging: Standard export carton packing.
FAQ:
|
Why choose us? Q1: Are you a factory or a trade company? A1: We're professional LED manufacturer of SMD LED, through-hole LED and digital LED display, providing one-stop OEM & ODM service to all partners all over the world.
Q2: Can I get some samples for tests? A2: Yes, we welcome sample order to test and evaluate our LED quality.
Q3: Is there any discount for bulk order? A3: Yes, we provide wholesale pricing for bulk orders and customized products.
Q4: How to choose LED light source ?
Q5: How to process the order? A5: 1. Let us know your requirements or application. 2. We will quote based on your requirements or our suggestions.
3. customer confirms the samples and places order, we will arrange production
|
