3W 3535 RGB LED 120 Degrees Dome Lens 3 In 1 Full Color Ceramic High Power SMD LED Factory Sell
Product Details:
| Place of Origin: | China |
| Brand Name: | BOSMFC |
| Certification: | Rohs, Reach |
| Model Number: | 3w 5050 RGB SMD LED |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1000pcs |
|---|---|
| Packaging Details: | 500pcs/reel, Reel+Anti-static bag+carton |
| Delivery Time: | 5-15 days |
| Payment Terms: | T/T, Western Union, paypal |
| Supply Ability: | 500KK/month |
|
Detail Information |
|||
| Application: | Indoor & Outdoor Lighting | Color: | RGB Light |
|---|---|---|---|
| Wavelength: | 620-635 / 515-525 / 460-473 Nm | Luminous Intensity: | 50/ 70/ 25 LM |
| Forward Current: | 350ma | Forward Voltage: | 1.8-2.4/2.8-3.4 /2.8-3.4v |
| Size: | 3.5*3.5*2.0mm | Warranty: | 3 Years |
| Lifetime: | 50000h | Operating Temperature: | -40℃~+85℃ |
| Reverse Voltage: | 5V | Storage Temperature: | -40℃~+100℃ |
| Highlight: | 3W 3535 RGB LED,3 In 1 3535 RGB LED,Full Color 120 Degrees Dome Lens |
||
Product Description
3W 3535 RGB LED 120 degrees dome lens 3 in 1 full color ceramic high power SMD LED, factory sell
Features:
- Well-known chip brands material
- 99.99% pure gold wire bonding
- High flux per LED
- Low-temp & lead-free reflow soldering
- More energy-efficient than incandescent and most halogen lamps
- Low Voltage DC operated
- Long lifespan 50,000 hours
Technical Parameters:
Electrical optical characteristics of 5050 Top smd led:(Ta=25°C)
| Parameter | Symbol | Color | Min | Typ | Max | Unit | Test Condition |
| Wavelength | λd | Red
Green Blue |
620
515 460 |
--- | 635
525 470 |
nm | IF=700mA |
| Luminous intensity | Iv | Red
Green Blue |
50
70 25 |
LM | IF=700mA | ||
| Forward voltage | VF | Red
Green Blue |
1.8
2.8 2.8 |
--- | 2.4
3.4 3.4 |
V | IF=700mA |
| Viewing angle | --- | 120 | --- | deg | IF=700mA | ||
| Reverse current | IR | --- | ---- | 5 | uA | IF=700mA |
| Operation Temperature | －40~+85℃ | Size | 3.5*3.5*2.0mm |
| Storage Temperature | －40~+100℃ | Packing | 1000pcs/reel |
Applications:
- Stage light
- Spot light
- Shot light
- Foutain light
- Landscape light
Materials:
Company information:
|
Dongguan Lanjin Optoelectronics Co., Ltd. established in 2005, a professional manufacturer in producing light emitting diode, LED digital display, SMD LED , through-hole LED and LED PCB assembly service. Covering 2,500 square meters factory plant, with modern purification constant termperature and humidity anti-static Our company has passed ISO9001:2015 international Quality management system certification, and now applying for ISO14001 Environmental management system certification. With 18 years development, we achieved 2 national invention patents, 12 practical new-type patents, 2 software invention patents, all products Lanjin has absorbed the advanced manufacturing technology of Japan, Korea and Western Europe. With a high starting point, high quality market positioning, developed high temperature resistance & long life LED. Widely used in communication equipment, swithching power supply, decorative lighting, multi-speaker, DVD and other Lanjin always addict to the principle of “ Quality and customer first”, provide customized services according to customer’s demand. LED light the world, Lanjin lights your life! |
Packing and Shipping:
Inner packaging: Anti-static Bag Vacuo Packaging
Outer packaging: Standard export carton packing.
FAQ:
Q1: Can I get some free samples for confirmation?
A: Yes, we are happy to provide sample orders for you to assess the quality and performance of our LED products. Free samples are available based on your requirements.
Q2: What about the lead time?
A: Sample needs about 3 working days. Customized products need 5-7 working days. Mass production 10-15 days.
Q3: What payment term do you accept?
A: We accept T/T, Paypal, Western Union .
Q4: How do you ship the goods and how long it will take?
A: We typically ship goods directly to your door using express services like DHL, UPS, FEDEX, or TNT. Delivery usually takes around 2-4 working days. Additionally, air and sea transportation options are available based on your needs.
Q5: How do you deal with the LED Failure issue?
A: Our engineering team will carefully investigate the failure by reviewing the photos of the defective products or rejected samples provided by our clients to identify the root cause. Should it be determined that the failure was due to an issue on Lanjin's part, we will swiftly arrange to send you a replacement batch of LED products.
Our LED products are produced under a rigorous quality control system, with each batch subjected to thorough inspection before shipment. This process guarantees that our defect rate is notably lower compared to other manufacturers.
