0.5w 5730 Top SMD LED Warm White CRI80 60-65lm Smd 5730 Led High CRI Led Chip For Photographic Lighting
Product Details:
| Place of Origin: | China |
| Brand Name: | BOSMFC |
| Certification: | Rohs, Reach |
| Model Number: | 5730 SMD LED |
Payment & Shipping Terms:
| Minimum Order Quantity: | 4000pcs |
|---|---|
| Packaging Details: | 1000pcs/reel, Reel+Anti-static bag+carton |
| Delivery Time: | 5-15 days |
| Payment Terms: | T/T, Western Union, paypal |
| Supply Ability: | 500KK/month |
|
Detail Information |
|||
| Application: | Indoor & Outdoor Lighting | Power: | 0.5W |
|---|---|---|---|
| Emitting Color: | Warm White, Natural White, Cool White | Color Temperature: | 2700-12,000K |
| Forward Current: | 150mA | Forward Voltage: | 3.0-3.4v |
| Luminous Flux: | 50-85lm | Viewing Angle: | 120° |
| Size: | 5.7*3.0*0.8mm | Color Rendering Index (Ra): | 80-95 |
| Operating Temperature(℃): | -40 - +85 | Storage Temperature(℃): | -40 - +100 |
| Lifespan: | 50,000 Hours | Warranty: | 3 Years |
| Chip Brand: | San'an Chip | Package: | 4000pcs/reel |
| Highlight: | 5730 Top SMD LED,0.5w SMD LED,5730 Led Chip |
||
Product Description
0.5w 5730 LED warm white CRI80 60-65lm smd 5730 led high CRI led chip for Photographic Lighting
5730 white SMD LED---Lanjin catalog.pdf
The 5730 SMD LED is a high-quality LED chip diode designed for LED lamp applications. With a power rating of 1W and a high voltage of 18V, provides bright and efficient white light illumination.
Features:
- Low energy consumption
- Long life-solid quality reliability
- Available on tape and reel
- RoHS compliant
- Suitable for all SMT assembly methods
- 99.9% pure gold wire
Technical Parameters:
Electrical optical characteristics of 2835 Top smd led:(Ta=25°C)
Parameter |
Symbol |
Color |
Min |
Typ |
Max |
Unit |
Test Condition |
Color temperature |
CCT |
warm White |
2700 |
--- |
3400 |
K |
IF=150mA |
Natural White |
4000 |
5000 |
|||||
Cold White |
6500 |
20,000 |
|||||
Luminous intensity |
Iv |
White |
50 |
--- |
85 |
LM |
IF=150mA |
Forward voltage |
VF |
White |
3.0 |
--- |
3.4 |
V |
IF=150mA |
Viewing angle |
|
|
--- |
120 |
--- |
deg |
IF=150mA |
Reverse current |
IR |
White |
--- |
---- |
5 |
uA |
IF=150mA |
Operation Temperature |
－40~+85℃ |
Size |
5.7*3.0*0.8mm |
Storage Temperature |
－40~+100℃ |
Packing |
1000pcs/reel |
Applications:
- Indoor and outdoor commercial light
- LED backlight and SMD type indicator
- LED module and LED strip light
- Decoration light, backlight in dashboards.
- Auto lamp, automotive electronics, traffic lights
- Mobile phone, digital camera, flash photoelectric display, backlight display
- LED Taillight, LED Brake Light ,In-vehicle lighting
Materials:
Company information:
|
Dongguan Lanjin Optoelectronics Co., Ltd. established in 2005, a professional manufacturer in producing light emitting diode, LED digital display, SMD LED , through-hole LED and LED PCB assembly service. Covering 2,500 square meters factory plant, with modern purification constant termperature and humidity anti-static production workshop. Our company has passed ISO9001:2015 international Quality management system certification, and now applying for ISO14001 Environmental management system certification. With 18 years development, we achieved 2 national invention patents, 12 practical new-type patents, 2 software invention patents, all products comply with the EU RoHS standard. Lanjin has absorbed the advanced manufacturing technology of Japan, Korea and Western Europe. With a high starting point, high quality market positioning, developed high temperature resistance & long life LED. Lanjin always addict to the principle of “ Quality and customer first”, provide customized services according to customer’s demand. LED light the world, Lanjin lights your life! |
Packing and Shipping:
Inner packaging: Anti-static Bag Vacuo Packaging
Outer packaging: Standard export carton packing.
FAQ:
Q1: Are you a factory or a trading company?
A1: We are a professional LED manufacturer of SMD LEDs, through-hole LEDs, and digital LED displays. We provide one-stop OEM & ODM services worldwide.
Q2: Can I get samples for testing?
A2: Yes, we welcome sample orders for testing and evaluating our LED quality.
Q3: Is there any discount for bulk orders?
A3: Yes, we provide wholesale pricing for bulk orders and customized products.
Q4: How do I choose an LED light source?
A4: When choosing an LED light source, factors such as lumens (LM), light efficiency (LM/W), and lifespan (hrs) are important. Higher values indicate better performance. Additionally, the brand of the LED chip, LED frame, and other materials can influence product reliability.
Q5: How do I process an order?
A5: The order process involves the following steps:
1.Let us know your requirements or application.
2.We will provide a quote based on your requirements or our suggestions.
3. After confirming the samples, you can place the order, and we will arrange production.
