Product Description:
The Through Hole LED is a versatile and reliable lighting component designed for a wide range of applications. Featuring a Dual In-line Package (DIP) mounting type, this LED offers ease of installation and robust mechanical stability, making it an ideal choice for both prototype development and mass production in various electronic devices. The DIP configuration ensures that the LED can be securely mounted on printed circuit boards (PCBs) with through-hole technology, providing enhanced durability and excellent electrical connections.
One of the standout features of this Through Hole LED is its impressive luminous flux, ranging between 60 to 70 lumens. This bright light output makes it highly suitable for indicator lights, display panels, backlighting, and other applications where clear, vibrant illumination is essential. The LED emits light at a wavelength corresponding to a color temperature of 6000K, which produces a cool white light that is crisp, clean, and visually appealing. This 6000K wavelength ensures that the light is neither too warm nor too harsh, striking a perfect balance for various lighting needs.
Durability and reliability are paramount in LED performance, and this Through Hole LED excels in these aspects with an operating temperature range from -40°C to +85°C. This wide temperature tolerance means the LED can function effectively in extreme environmental conditions, from freezing cold to intense heat. Such resilience is crucial for outdoor applications, automotive lighting, and industrial equipment where temperature fluctuations are common.
In addition to its mechanical and operational strengths, this Through Hole LED boasts a reverse breakdown voltage of 35V. This characteristic ensures that the LED can withstand voltage spikes and reverse polarity situations without damage, enhancing the longevity and safety of the electronic circuits in which it is used. This high reverse breakdown voltage is particularly beneficial in circuits prone to transient voltage conditions, providing an extra layer of protection.
Modern LED technology has seen significant advancements, and this Through Hole LED incorporates elements inspired by COB LED (Chip on Board LED) technology. Although it is a through-hole component, the LED benefits from design principles similar to those used in Chip LED Cob modules. These principles include improved thermal management, higher luminous efficiency, and better light distribution. By integrating the advantages of Chip LED Cob design into a DIP mounting format, this LED offers a unique combination of traditional assembly methods with cutting-edge performance features.
Chip LED Cob technology is known for its compact and efficient light sources where multiple LED chips are packaged closely together on a single substrate. While the Through Hole LED is not a direct COB LED module, it shares many of the benefits associated with Chip LED Cob, such as enhanced brightness and superior light quality. This makes it an excellent choice for applications requiring consistent and high-quality illumination without the complexity of surface-mount technology.
Whether used in consumer electronics, automotive lighting, signage, or industrial equipment, the Through Hole LED stands out as a dependable and efficient lighting component. Its combination of DIP mounting type, high luminous flux, stable operating temperature range, and robust electrical characteristics ensures that it meets the demands of diverse applications. Furthermore, its design influenced by Chip LED Cob technology provides enhanced performance and reliability, making it a smart choice for engineers and designers seeking a balance between traditional mounting methods and modern LED efficiency.
In summary, this Through Hole LED offers a compelling blend of classic and contemporary LED features. With a luminous flux of 60-70 lumens, a color temperature of 6000K, an operating temperature range from -40°C to +85°C, and a reverse breakdown voltage of 35V, it is built to deliver excellent performance in challenging environments. Its incorporation of COB LED and Chip LED Cob design principles further elevates its functionality, ensuring bright, consistent light output and long-lasting durability. This product is an excellent solution for anyone looking to integrate high-quality LED lighting with the reliability and simplicity of through-hole mounting technology.
Features:
-
Product Name: Through Hole LED
-
Chip SMD LED technology for enhanced performance
-
High Lumen LED Chip delivering luminous flux of 60-70LM
-
Working Current: 30mA for efficient power consumption
-
Speed: Small Signal =< 200mA (Io), suitable for any speed application
-
Wavelength: 6000k for bright and clear illumination
-
Packing: 500pcs per ESD Bag for safe handling and storage
-
Reliable Chip SMD LED construction ensures durability and longevity
Applications:
The Through Hole LED with DIP mounting type and water clear lens appearance is an ideal lighting solution for a wide range of applications and scenarios. Thanks to its high lumen LED chip technology, this LED delivers a luminous flux of 60-70 lumens at a working current of 30mA, providing bright and efficient illumination. Its wavelength of 6000K ensures a cool white light output that is perfect for environments requiring clear and crisp lighting.
One of the primary application occasions for this Through Hole LED is in indicator lights and display panels. The high lumen LED chip ensures that the indicators are visible even in brightly lit environments, making it suitable for use in industrial machinery, consumer electronics, and control systems. The DIP mounting type offers easy and reliable installation on printed circuit boards (PCBs), making it a preferred choice for manufacturers seeking durability and efficiency.
This LED is also widely used in automotive lighting applications. The water clear lens coupled with the COB LED design provides a focused and uniform light beam, enhancing visibility and safety in vehicle lighting such as dashboard indicators, signal lights, and interior illumination. Its robust construction and consistent performance under a working current of 30mA make it a dependable component in the automotive sector.
In addition, the Through Hole LED is suitable for decorative and architectural lighting scenarios where high brightness and reliability are essential. The cool white light of 6000K adds a modern and clean aesthetic to displays, signage, and accent lighting. The high lumen LED chip technology ensures long-lasting brightness, reducing the need for frequent replacements and maintenance.
Furthermore, this LED finds applications in medical devices and instrumentation where precise and clear lighting is crucial. The water clear lens and high lumen LED chip provide accurate illumination necessary for diagnostic and monitoring equipment. The COB LED construction enhances thermal management, ensuring stable performance during extended use.
Overall, the Through Hole LED with DIP mounting, water clear lens, and high lumen LED chip technology is a versatile and efficient lighting component. Its robust luminous flux, cool white wavelength, and consistent current rating make it suitable for a diverse range of occasions and scenarios, from industrial controls and automotive lighting to decorative, medical, and consumer electronic applications.
Customization:
Our Through Hole LED product offers extensive customization services to meet your specific requirements. With an operating temperature range from -40°C to +85°C, it is designed to perform reliably in various environments. The LEDs are packed in 500pcs per ESD bag to ensure safe handling and delivery.
These LEDs feature a DIP mounting type, making them easy to install in your applications. They support small signal currents up to 200mA (Io) at any speed, providing flexibility for diverse electronic designs.
We provide customization options including COB LED, IR LED, and High Lumen LED Chip configurations to suit your lighting and signaling needs. Whether you require infrared functionality or high brightness, our Through Hole LEDs can be tailored accordingly.
Contact us to customize your Through Hole LED solution with optimal performance and packaging that fits your project requirements.
Support and Services:
For technical support and services related to Through Hole LED products, please refer to the product datasheets and application notes available on our website. Our support team is dedicated to assisting you with product selection, circuit design, and troubleshooting to ensure optimal performance of your LED applications.
We offer comprehensive services including product customization, reliability testing, and evaluation samples to meet your specific requirements. Detailed guidelines on soldering, mounting, and handling Through Hole LEDs are also provided to enhance product longevity and efficiency.
For warranty information, repair services, and replacement policies, please review the terms and conditions outlined in the product documentation. Our technical support specialists are available to provide expert advice and answer any inquiries related to Through Hole LED products.
Additional resources such as FAQs, user manuals, and software tools can be accessed through our support portal. We strive to deliver prompt and effective solutions to support your projects and ensure your satisfaction with our Through Hole LED products.
FAQ:
Q1: What is a Through Hole LED?
A Through Hole LED is a type of light-emitting diode with leads that are designed to be inserted into holes on a printed circuit board (PCB) for soldering. It is commonly used for indicator lights and displays.
Q2: What are the typical colors available for Through Hole LEDs?
Through Hole LEDs are available in various colors including red, green, blue, yellow, white, and infrared, allowing for versatile applications.
Q3: What is the standard operating voltage for a Through Hole LED?
Most Through Hole LEDs operate between 1.8V to 3.3V depending on the color and type. It's important to check the specific datasheet for accurate voltage requirements.
Q4: What is the typical lead spacing for Through Hole LEDs?
The standard lead spacing for Through Hole LEDs is usually 5mm (0.2 inches), which fits most through-hole PCBs.
Q5: Can Through Hole LEDs be used with microcontrollers?
Yes, Through Hole LEDs can be easily interfaced with microcontrollers for visual indicators, status signals, or simple light effects by connecting them through appropriate current-limiting resistors.
